50-Pin Centronics / Amphenol / RJ-21 Breakout Board
- 50-Pin Centronics (RJ-21 / CHAMP) connector
- Amphenol to Screw Terminal adapter
- Perfect for prototyping and permanent installations
- Screw terminal for each of the 50 lines, plus shield
- Solder pad connection space for all 50 lines plus shield
- Supports addition of .1" pin headers
- Double deck screw terminals provide compact wiring
- Fast and easy connections
- Rubber feet or DIN rail mount
General Description
Make connections quickly and reliably with this breakout board, which brings every pin of its 50-pin Centronics connector out to screw terminals.
Each pin, including shield, is also brought to solder pads (3 per pin) at 0.1" spacing, allowing easy addition of pin headers or other components. Please note that the breakout boards are manufactured with a connection between each connector pin and the corresponding terminal block position; no soldering of any type is necessary. The solder pads simply provide an area for making optional connections to additional headers or other components.
This breakout board is perfect for production applications as well as experimentation and prototype work. It is well-suited for interfacing with data acquisition equipment, phone systems, or any other devices that use the RJ-21 50-pin Centronics connector.
Centronics connectors are also referred to as a CHAMP or Amphenol connectors. The 50-Pin Centronics is sometimes called a 50-pin telco or RJ-21 connector.
A breakout board is sometimes referred to as a "transition module", "terminal board", "terminal block", "breakout box", "breakout adapter", "terminator", or "interface module".
Product Documents
| Part # | Description | Data Sheet | PDF Drawing | DWG Drawing | IGES Model | STEP Model | Document |
|---|---|---|---|---|---|---|---|
| BRKDC50F-R-DIN | 50-pin Centronics, Right Angle, DIN Mount |
|
|
|
|
| |
| BRKDC50F-R-FT | 50-pin Centronics, Right Angle, Rubber Feet |
|
|
|
|
| |
| Connector Guide | Which connector do I have? Consult this helpful identification guide. |
|
50-pin Centronics, Right Angle, DIN Mount
50-pin Centronics, Right Angle, Rubber Feet
Which connector do I have? Consult this helpful identification guide.
Mounting Options
These products are available in two different mounting variants. Product numbers ending with -DIN come with DIN clips already installed and ready to snap onto 35mm or 32mm DIN rail. Product numbers ending with -FT have stick-on rubber feet installed on the bottom side, allowing for benchtop use or panel mounting. For panel mounting, we suggest 1/4" nylon standoffs under the mounting holes, and #6 screws.BRKDC50F-R-DIN
Click image to enlarge. Rail not included
BRKDC50F-R-FT
Click image to enlarge.Product Details
- Centronics 50-Pin / CHAMP / Amphenol / RJ-21 connector
- Screw terminal for each of the 50 lines, plus shield
- Solder pad connection holes, three (3) per line
- Supports addition of .1" pin headers
- Screw terminals accommodate wire sizes from 16AWG to 26AWG
- Approximate dimensions: 3.15" x 4.7"
- Rubber feet or DIN rail mount
Pricing and Ordering
| Product # | Description | 1+ | 10+ | RoHS | Buy Now |
|---|---|---|---|---|---|
Centronics 50-Pin Female Right Angle Connector: |
|||||
| BRKDC50F-R-DIN | Centronics 50-Pin Female Breakout Board, R/A Connector, DIN Rail Mount | $58.30 | $55.10 | Yes | |
| BRKDC50F-R-FT | Centronics 50-Pin Female Breakout Board, R/A Connector, Feet | $56.70 | $53.50 | Yes | |
| Quantity | Price |
|---|---|
| 1+ | $58.30 |
| 10+ | $55.10 |
| Quantity | Price |
|---|---|
| 1+ | $56.70 |
| 10+ | $53.50 |
All of the above items are normally stocked. Please call us if you need to verify availability for a specific quantity, or for pricing at higher quantities. Please visit our ordering page for our ordering policies and a list of ordering methods.
