Universal DIN Rail Mounting Plates - Aluminum
Many devices are not designed for DIN rail mounting, but these universal DIN rail mounting plates solve that problem. Simply attach your device to the plate by using screws, and then mount the assembly onto your 35mm DIN rail.
Winford offers these plates in a variety of sizes, mounting options, and DIN clip styles, and the plates themselves are made from sturdy Aluminum plate, and come in several options.
- solid plate (customer drills their own holes for device mounting)
- pre-drilled grid of mounting holes
- pre-drilled mounting holes near the corners of the plate
- pre-routed mounting slots that can be used with metric or imperial cage nuts
For a full list of all of the models in this product line and the differences between them, see the table at the bottom of this page.
Product Number Breakdown
Our product numbers can get a little confusing, especially since there are many product variants available. So here's a breakdown of what they mean. Note that we do not currently build all possible combinations of options; see selection matrix at the bottom of the page for all stocked parts.
| DINP | 0X | - XXXX | X | |
|---|---|---|---|---|
| Type | ||||
| DINPA Plate made of Aluminum | ||||
| See other material options here. | ||||
| DIN Clip | ||||
| 01 44.2mm DIN Clip | ||||
| 02 25mm DIN Clip | ||||
| 03 Right Angle DIN Clip, Plate on Left | ||||
| 08 44.2mm DIN Clip with standoffs | ||||
| 12 25mm DIN Clip with standoffs | ||||
| Plate Size | ||||
| xxyy x.x" width × y.y" height | ||||
| 4060 4.0" x 6.0" (Example) | ||||
| ... | ||||
| See more sizes of other materials here. | ||||
| Mounting Options | ||||
| A Solid Plate | ||||
| B Mounting Holes Grid | ||||
| E Several Mounting Holes | ||||
| J Slots for Metric Cage Nuts | ||||
| K Slots for Imperial Cage Nuts | ||||
DINP Product Selection Matrix
| Plate Size/ Material |
Clip Width | Solid Plate | Mount Holes | Mount Slots | Right Angle Bracket | Stand-offs | DIN Rail Section | |
|---|---|---|---|---|---|---|---|---|
 DINPA12-1080x |
1.0" x 8.0" Aluminum |
25mm | (Cage Nuts) |
|
||||
 DINPA01-2060E |
2.0" x 6.0" Aluminum |
44.2mm | |
|
||||
 DINPA03-3040E |
3.0" x 4.0" Aluminum |
25mm | |
|
|
|||
 DINPA01-4040B |
4.0" x 4.0" Aluminum |
44.2mm | |
|||||
 DINPA01-4040E |
4.0" x 4.0" Aluminum |
44.2mm | |
|
||||
 DINPA03-4040A |
4.0" x 4.0" Aluminum |
25mm | |
|
||||
 DINPA03-4040E |
4.0" x 4.0" Aluminum |
25mm | |
|
|
|||
 DINPA02-4060B |
4.0" x 6.0" Aluminum |
25mm | |
|||||
 DINPA03-4060A |
4.0" x 6.0" Aluminum |
25mm | |
|
||||
 DINPA08-4060x |
4.0" x 6.0" Aluminum |
44.2mm | (Cage Nuts) |
|
Other Mounting Plate Options
Winford Engineering offers several varieties of mounting plates with various sizes, materials, and mounting options. See the entire list of plates.
